Homeline

Square D Homeline panels and breakers are for wiring projects where you’re choosing a load center and the breakers to go with it. Fully convertible mains and top or bottom feed give you flexibility when planning the panel’s configuration and incoming feed.

Homeline is Square D’s family of load centers and circuit breakers. Schneider Electric offers the line under the Square D name. Square D QO/QOB is a separate product family.

Match the breakers to the panel

Homeline load centers are compatible with Homeline 1-inch circuit breakers. Choose the panel and breakers together. Start your breaker list with that family, then match each breaker to its circuit’s requirements.

Choose Plug-on Neutral at the planning stage

Homeline offers a Plug-on Neutral solution for enclosures with eight spaces or more. Make that choice while you’re selecting the panel, so the load center and compatible Plug-on Neutral breakers are planned together.

The fully distributed neutral bar provides neutral connection points along the bar. Include those locations when planning conductor routing inside the enclosure.

Configure the load center around the job

Homeline’s fully convertible mains give you flexibility in the main configuration. Settle the required main arrangement while choosing the enclosure so the parts list follows the job.

Top or bottom feed is useful when the incoming route is already set by the building. Plan the panel layout around where that feed will enter.

Homeline specifications

Feature	Detail
Compatible breaker family	Homeline 1-inch circuit breakers
Mains	Fully convertible
Feed	Top or bottom
Plug-on Neutral availability	Solution for all enclosures with eight spaces or more
Neutral bar	Fully distributed
Bus bars	Tin- and copper-plated aluminum

Frequently Asked Questions

What’s the difference between Square D QO and Homeline?

Square D Homeline and QO are separate product families. Homeline load centers accept Homeline 1-inch circuit breakers, so keep that family designation straight when you’re matching breakers to the panel.

What is Square D Homeline used for?

Square D Homeline is a family of electrical load centers and circuit breakers. The load center distributes incoming power to individual circuits, and the breakers protect those circuits from excess current. You’re selecting a panel and the breakers that belong in it as one system.

Can you get a Homeline panel with Plug-on Neutral?

Square D Homeline offers a Plug-on Neutral solution for all enclosures with eight spaces or more. If you want that setup, check compatibility between the particular panel and breakers before you put the parts list together.

How do you wire a Homeline load center?

Square D Homeline supports top or bottom feed, so you can plan the incoming route around the job. The actual terminal connections, conductor requirements and tightening specifications depend on the exact panel and need to follow its installation instructions. Feed direction is a layout choice, not a complete wiring plan.
